Machine specification 1.The machine control system is PLC+touch screen,the tension is controlled by magnetic clutch,easy to operate 2.Adopt frequency converter control 2 main motor,auto meter counter and alarm.Used A and B air expanding shaft. 3.Used web guide sensor for unwind shaft,irregular material will be easy to slit. 4.Equipped with vertical knife structure and automatic waste film blowing system 5.Used air expanding shaft for unwind shaft. Machine parameter 1100 Max unwind width: 1100mm Max unwind diameter: 700mm Min slitting width:30mm Max rewind diameter:550mm Speed:10-450m/min Machine power:12kw Power supply 380V/50HZ Weight: 2100kgs Machine dimension:2000*2250*1350mm Machine parameter 1300 Max unwind width: 1300mm Max unwind diameter: 700mm Min slitting width:30mm Max rewind diameter:550mm Speed:10-450m/min Machine power:12kw Power supply 380V/50HZ Weight: 2300kgs Machine dimension:2000*2450*1350mm Machine parameter 1600 Max unwind width: 1600mm Max unwind diameter: 700mm Min slitting width:30mm Max rewind diameter:550mm Speed:10-450m/min Machine power:15kw Power supply 380V/50HZ Weight: 2600kgs Machine dimension:2000*2650*1350mm
